Material: High-Speed-Steels（HSS）, Powder-Metal-Steels（PM - HSS）, Carbide
Outside diameter: Φ6 ～ Φ350
Module: m0.2 ～ m28
Quality: DIN1829 AA, A
Coating: Oerlikon - Balzers
Keyway: Transverse keyway and other keyway
Comdition: Wet; Dry; Soft; Hard
Struction: Disk-type; Deep-counterbore-type; Taper-shank-type; Straight-shank-type
Helix angle: ±45°
Profile: Chamfer, Root fillet, Tip relief, Protuberance, Full radius, Topping, Semi-
topping on top are possible modifications that can be combined with each other.
We manufacture all kinds of shaper cutters.
Solid HSS shaper cutters
Soild Carbide shaper cutters
Involut Spline shaper cutters
involute Serration shaper cutters
Parallel side spline shaper cutters
Roller chain sprocket shaper cutters
Belt wheels shaper cutters
Skiving gear shaper cutters
Fellows-type shaper cutters
Sykes-type shaper cutters
Helical teeth shaper cutter; Combined teeth shaper cutter
Small diamter and small module shaper cutter
Helical teeth shaper cutter with transverse keyway
Pot type shaper cutter
Sykes-type shaper cutters
Fellows-type shaper cutters
Roller chain sproket shaper cutter （Non-involute gear shaper cutter）
Serration spline shaper cutter
Parallel side spline shaper cutter
|
